HEAVY DUTY SERVICE
667X Pintle, tensile strength 21,000 lbs., 7/16 pins with steel back plate
1/2" thick rubber flights with 4 rivets, 12" spacing
We know of no one making flighting with specifications comparable to those listed above
REGULAR SERVICE
Duplicates industry standards using American made pintle chain
667H chain, tensile strength 9500 lbs., 5/16 pins with steel back plate
1/2" thick rubber flights with 4 rivets, 14" spacing
ECONOMY SERVICE
Duplicates industry standards using American made pintle chain
667H chain, tensile strength 9500 lbs., 5/16 pins with steel back plate
1/2" thick rubber flights with 4 rivets, 17" spacing
#62 FLAT
Detachable chain uses quality American made chain, back plates, and rubber flights with 1/2" thick rubber flights with 2 rivets, 14" spacing
#662 PINTLE
This pintle chain also uses American made chain, back plates, and flights with 1/2" thick rubber flights with 2 & 4 rivets, 14" spacing
